Screw vacuum pumps - VADS
Driven directly by an integrated frequency inverter, these pumps no longer require any drive transmission. The area in which the units work is 100% oil-free. The integrated speed governor optimises the use of energy by matching delivery to actual demand. This creates high efficiency levels and minimises energy consumption. Suction air remains pulsation-free all of the time.
Various accessories, such as intake filter, non-return valve, sound absorbers as well as the air delivery and discharge system, are integrated in the completely soundproof cover structure.
wAdvantages:
- Direct-drive, no transmission required
- 100% oil-free compression
- 100% contact-free and non-wearing compression
- Integrated frequency converter
- Continuous output controlling
- Small oil circuit for synchronisation transmission
- Operating/ error messages shown in display
- Compact unit, integrated accessories
- Low noise levels
- Lower maintenance requirements
- Pulsation-free air vacuum and blast air
- High degree of efficiency, low energy requirements
- Modern design
| type | max. suction air rate [m3/h] 50/60Hz |
max. vacuum [mbar abs.] 50/60Hz |
max. vacuum [mbar rel.] 50/60Hz |
max. motor capacity [KW] 50/60Hz |
|---|---|---|---|---|
| VADS 250 | 240 | ≤ 0,1 | ≤ -999,9 | 7,5 |
| VADS 1500 | 1420 | 200 | -800 | 37 |
