The active pulsation dampener is the most efficient way to remove pressure variations on the discharge of the pump.
The Tapflo pulsation dampener works actively with compressed air and a diaphragm, automatically setting the correct pressure to minimize the pulsations.
POLYETHYLENE (PE) DAMPENERS
Hi-Density Polyethylene (PP HD) has better physical and chemical parameters than standard polypropylene (PP). It is several times more resistant to wear what makes this material ideal for abrasive and aggressive liquids. It can also withstand liquid temperature up to 70°C.
PTFE DAMPENERS
PTFE is excellent for use in applications requiring high temperatures. It may also be used for very aggressive fluids such as chlorinated hydrocarbons and highly aggressive acids. Maximum liquid temperature is 100°C
ALUMINIUM DAMPENERS
The aluminium dampeners are perfect to use for pH-neutral fluids. They have great resistance to corrosion and deterioration. They can be found in many applications from workshop, through paint industry to chemistry.
AISI 316 STAINLESS STEEL DAMPENERS
Dampeners made of stainless steel offer great mechanical strength combined with good chemical resistance. AISI 316 is resistant to aggressive and abrasive liquids. The dry part of the dampener that does not come into contact with the pumped product is, as a standard, made of corrosive resistant PP.
SANITARY DAMPENERS
The sanitary series of Tapflo dampeners has been designed in particular for food, beverage, pharmaceutical and cosmetic industries where cleanliness and sterile environment is necessary.
MADE TO BE CLEAN
The dampener is designed and prepared for cleaning and sterilization in place – C.I.P. and S.I.P. These are automatic cleaning and disinfection procedures implemented in these industries so it is essential that our product are prepared to comply with these procedures.
ATEX CERTIFIED DAMPENERS
The dampeners are available in explosion proof – ATEX marked – execution. They are supplied with earth connection and conductive materials: conductive body, diaphragm in PTFE (conductive backing) or EPDM (conductive).
Read more: Pulsation dampeners
