Lubrication Pumps
1000 Series Lubrication Pumps
The 1000 Series is based on the proven internal gear principal and is enhanced in response from our OEM customers for a pump that offers advanced features which make installation easier. These side-ported pumps have the option to bolt SAE/DIN flanges onto them ensuring maximum flexibility on the porting arrangements. Our pump meets your technical requirements and is easily fitted into your system. Our manufacturing expertise and knowledge of applications enable us to provide you with an engineered solution and ensure satisfaction with post-sales service. We pride ourselves on properly servicing you with specification, installation, operation, and troubleshooting. The pump was originally designed to meet and exceed the exacting requirements of the refrigeration compressor market. The design has so many inherent features and benefits that our traditional customers are also seeing the advantages. The 1000 series with great performance is solving problems in many industries and applications.
4000 Series
4000 Series PROCESS PUMPS run quiet and provide reliable performance with minimal downtime and maintenance, a positive displacement internal gear construction, and accurate repeatable flow. Special materials of construction permit handling applications in the chemical, food, and petroleum process industries and a wide variety of fluids without solids, as well as a wide variety of fluids including abrasive fluids. Some examples are- (adhesives, alcohol, asphalt, barium sulfate slurry, benzene, coatings, creosote, crude oil, diatomaceous earth, enamel, ethylene glycol, fats, fuel oils, fuller’s earth, gasoline, glue, iron oxide slurry, kerosene, lacquer, lard, linseed oil, liquid feed, molasses mineral oil, paint, paper coating, petrolatum, printing ink, soap liquors, solvents, tall oil, transformer oil, varnish, vegetable oils, and wax)
(ANY LIQUID that contains abrasive contaminants compatible with cast iron construction). This list is for general guidance only. For applications involving other fluids, higher temperatures, or unusual processing conditions, PLEAS CONSULT FACTORY.
C Series Circulation Pumps
The L & C Series cast iron positive displacement pumps have been the industry standard for Lubrication & Circulation for over 75 years. They were originally designed under James B. Tuthill, the company’s founder, in the 1920s. For eight decades, Tuthill has worked to improve these pumps to fit an ever-growing range of lubrication applications. The result is a family of reliable internal gear pumps that are ideal for custom OEM lubricating, lowpressure hydraulic, transfer, circulating, burner oil and many other industrial pump applications.
CC Series Close Coupled Pumps
With lots of pump performance in a relatively small space, the CC Series is ideal for package pumping skids or applications where space is limited. By eliminating the need for adapters, reducers, couplings, bases and guards the CC Series saves on cost and eliminates the need for maintenance of these components down the road.
L Series Lubrication Pumps
The L Series is an internal gear pump design with compact and flexible drive options. This pump series is available with Tuthill's Reversing Feature, comes standard with a single mechanical seal and cast iron construction
Stripped Lubrication Pumps
Flow rates to 84 usgpm. (19.3 m3/hr)
Pressures to 150 psi. (10.3 bar)
Model #'s- 2C, 3C, 4C, 5C, 6C
TR Series Lubrication Pumps
Strictly OEM applications. Directly mounted on rotating equipment where the pump is built onto the end of a shaft in the equipment. Pump consists of six parts which the customer assembles on his equipment. Lubrication duty only. Unique, compact, gerotor pump design. Pump is reversible and has inherent pressure relief capability.
