Filter press pumps
The Tapflo pump station for filterpress feeding is a very compact unit that can be mounted directly to the filterpress. The design and function allows the user a straightforward pressing of slurries.
HOW THEY WORK
Pressure regulator is already mounted to the unit. The pump stations are based on the standard Tapflo pumps from machined polyethylene (PE). An external pressure booster doubles the delivery pressure. For example, with available air pressure of 7 bar, the delivery pressure will be maximum 14 bar.
THE INSTALLATION
As this station works self-regulating, an additional device for regulating the flow quantity is not necessary. Just mount it to the filterpress, connect it – ready.Even the pressure regulator for the air supply is included. For monitoring the filling-level of the filterpress, stroke sensors and stroke counters are available.
PE & PTFE TF PUMP RANGE
► TF50, 50 lit/min - 1/2"
► TF100, 100 lit/min - 1"
► TF200, 200 lit/min – 1 1/2”
► TF400, 400 lit/min – 2”
